For the Firewire-based FLEX-5000 and FLEX-3000 connected to Win7 PCs, you may experience intermittent connection behavior due to software defects in the native Win7 1394 bus driver that interfaces with your Firewire card. The following instructions describe how to revert to the legacy 1394 Host controller bus driver. USB and IEEE-1394 (FireWire) are low-cost, high-speed connections for computer peripherals. These connections allow you to connect a computer to such devices as printers, portable storage devices, joysticks, keyboards, mouse devices, scanners, modems, digital speakers, removable drives, and many other devices.

-->

Windows 7 includes 1394ohci.sys, a new IEEE 1394 bus driver that supports faster speeds and alternative media as defined in the IEEE-1394b specification. The 1394ohci.sys bus driver is a single (monolithic) device driver, implemented by using the kernel-mode driver framework (KMDF). The legacy 1394 bus driver (available in earlier versions of Windows) includes multiple device drivers that were implemented by using the Windows Driver Model (WDM) in a port/miniport configuration. The 1394ohci.sys bus driver replaces the legacy port driver, 1394bus.sys, and the primary miniport driver, ochi1394.sys.

Installing IEEE 1394 Device Drivers. This section provides installation information, specific to IEEE 1394 device drivers in Microsoft Windows 2000 and later operating systems. Vendors supplying their own IEEE 1394 device driver should make that driver a member of the Base setup class in the INF Version Section of the driver's INF file.

The new 1394ohci.sys bus driver is fully backward compatible with the legacy bus driver. This topic describes some of the known differences in behavior between the new and the legacy 1394 bus driver.

Note

Firewire ieee 1394 driver windows xp

The 1394ohci.sys driver is a system driver that is included in Windows. It is automatically loaded when you install a 1394 controller. This is not a redistributable driver that you can download separately.

I/O Request Completion

All I/O requests that are sent to the new 1394 bus driver return STATUS_PENDING because the 1394ohci.sys bus driver is implemented by using KMDF instead of WDM. This behavior differs from that of the legacy 1394 bus driver, in which certain I/O requests complete immediately.

Firewire Ieee 1394 Driver For Windows 10

A client driver must wait until I/O requests sent to the new 1394 bus driver are complete. You can provide an I/O completion routine that is called after the request is complete. The status of the completed I/O request is in the IRP.

Configuration ROM Retrieval

The new 1394 bus driver tries to use asynchronous block transactions at faster bus speeds to retrieve the contents of a node's configuration ROM. The legacy 1394 bus driver uses asynchronous quadlet reads at S100 speed—or 100 megabits per second (Mbps). The 1394ohci.sys bus driver also uses the values that are specified in generation and max_rom entries of the node's configuration ROM header to improve the retrieval of the remaining content of the configuration ROM. For more information about how the new 1394 bus driver retrieves the contents of a node's configuration ROM, see Retrieving the Contents of a IEEE 1394 Node's Configuration ROM.

IEEE-1394-1995 PHY Support

The 1394ohci.sys bus driver requires a physical layer (PHY) that supports IEEE-1394a or IEEE-1394b. It does not support a PHY that supports IEEE-1394-1995. This requirement is due to the 1394ohci.sys bus driver's exclusive use of short (arbitrated) bus resets.

NODE_DEVICE_EXTENSION Structure Usage

A client driver can reference the device extension in the 1394 bus driver associated with the physical device object (PDO) for the device that the client driver controls. This device extension is described by the NODE_DEVICE_EXTENSION structure. In 1394ohci.sys, this structure remains at the same location as in the legacy 1394 bus driver, but the nonstatic members of the structure might not be valid. When a client driver uses the new 1394 bus driver, they must make sure that the data accessed in NODE_DEVICE_EXTENSION is valid. The static members of NODE_DEVICE_EXTENSION that contain valid data are Tag, DeviceObject, and PortDeviceObject. All other members NODE_DEVICE_EXTENSION are nonstatic, which the client driver must not reference.

Driver

Gap Count Optimization

The default behavior of the 1394ohci.sys bus driver is to optimize the gap count when it finds only IEEE 1394a devices on the 1394 bus, excluding the local node. For example, if the system that is running 1394ohci.sys has a host controller that complies with IEEE 1394b but all devices on the bus comply with IEEE 1394a, then the new 1394 bus driver tries to optimize the gap count.

Gap count optimization occurs only if the 1394ohci.sys bus driver determines that the local node is the bus manager.

The 1394ohci.sys bus driver determines whether a device complies with IEEE-1394a by the speed setting in the node's self-id packet. If a node sets both of the bits in the speed (sp) field in the self-id packet, then 1394ohci.sys considers the node to comply with IEEE-1394b. If the speed field contains any other value, then 1394ohci.sys considers the node to comply with IEEE-1394a. The gap count value that is used is based on table E-1 in the IEEE-1394a specification, which provides the gap count as a function of hops. The 1394ohci.sys bus driver does not compute the gap count. You can change the default gap count behavior by using a registry value. For more information, see Modifying the Default Behavior of the IEEE 1394 Bus Driver.

Drivers Ieee 1394 Firewire Windows 7

Device Driver Interface (DDI) Changes

In Windows 7, the 1394 DDIs were changed to support faster speeds as defined by the 1394b specification and improved to simplify the development of 1394 client drivers. For more information about the general DDI changes that the new 1394 bus driver supports, see Device Driver Interface (DDI) Changes in Windows 7.

Related topics

The IEEE 1394 Driver Stack
Retrieving the Contents of a IEEE 1394 Node's Configuration ROM

  1. Download the Microsoft Firewire 1394 Legacy Driver Installer
  2. Double-click to run the 1394_OHCI_LegacyDriver.msi file. This will extract the drivers to: C:Program Files (x86)1394 OHCI Compliant Host Controller (Legacy)
  3. Open the folder: C:Program Files (x86)1394 OHCI Compliant Host Controller (Legacy)X64_driver
  4. Right-click on Legacy1394.inf and choose Install to install the drivers
  5. Press the Windows Key + R
  6. Type devmgmt.msc
  7. Click OK
  8. In Device Manager, expand IEEE 1394 Bus Host Controllers
  9. Right-click on 1394 OHCI Compliant Host Controller
  10. Click Update Driver Software
  11. Click Browse my computer for driver software
  12. Click Let me pick from a list of device drivers on my computer
  13. Click 1394 OHCI Compliant Host Controller (Legacy)
  14. Click Next
  15. (When Windows has finished installing the driver) click Close
